Chapter 4: Effect parameters
EFF: PAN
DEP Modulation Depth 0 - 1 0 0 %
DIR Direction
L L —^ pans the signal from L to R.
R R <— pans the signal from R to L.
L < - 4 R L R pans the signal from L to R to L, etc.
MIX Mixing Balance 0 - 1 0 0 %
0 = dry signal.
50 = 50% auto pan effect. 50% dry signal.
100 = 100% auto pan effect.
LVL Output Level - oo^ -30 dB - +6 dB Sets the output level of the effect.
Typ Filter Type HPF, LPF
Frq Cut Off Frequency
HPF:THRU,
32 Hz - 1.0 kHz
LPF: 1.0 k H z - 1 6 kHz,
THRU
EFF: TRM
LFO Wave Type SIN, TRI, SQR SIN:Sine, TRI:Triangle, SQR:Square
MIX Mixing Balance 0 - 1 0 0 %
0 = dry signal.
50 = 50% tremolo effect 50% dry signal.
100 = 100% tremolo effect.
LVL Output Level - oo, -30 dB - +6 dB Sets the output level of the effect.
Typ Filter Type HPF, LPF
Frq Cut Off Frequency
HPF:THRU,
32 Hz - 1.0 kHz
LPF: 1.0 k H z - 1 6 kHz,
THRU
20
