Rev 6.0/5-14 3 MRTALPR4-DC: #35057
SPECIFICATIONS
Maximum Load Capacity: 600 lbs [270 kg] based on Maximum Per-Pad Load Capacity of 150 lbs [68 kg], rated at 16" Hg
[-54 kPa] on clean, smooth, nonporous flat surfaces 1
Power Source: 12 volts DC, 5 amps
Battery Capacity: 18 amp-hours
Tilt Capability: Manual, 90°, with mechanical advantage that minimizes operator effort and automatic latching in
upright position
Rotation Capability: Manual, 180°, with automatic latching at every 30° of revolution (when desired)
Vacuum Pump: Diaphragm type, 2.5 SCFM [71 liters/minute] nominal airflow
Dual Vacuum System: 2 vacuum system circuits allow the lifter to maintain the vacuum level in one circuit even if an
unexpected vacuum loss occurs in the other one (eg, due to load breakage).
Vacuum Reserve Tanks: 2 vacuum reservoirs help prevent immediate vacuum loss in case of power failure and extend
battery life by reducing pump cycles required to maintain vacuum.
Vacuum Gauges: 2 dial gauges indicate current vacuum level in positive inches of Hg and negative kPa.
Vacuum Lift Light: Green light is energized when vacuum is higher than the level required to lift the maximum load
weight (16" [-54 kPa]).
Low Vacuum Warning Buzzer: Maximum Alarm Volume = 103 dBA at 2 ft [60 cm]. While the lifter is powered up, an
audible alarm warns the operator whenever vacuum is not sufficient for lifting the maximum load
weight.
Options: Available with Model EO8RC1 - Remote Control System. This option features a radio transmitter
and receiver that can activate apply and release functions at distances up to 250 ft [76 m]. The
system uses either a 310-320 or a 433-434 MHz signal, depending on requirements in your
geographical location. See separate instructions about other options.
Available with Pad Frame Extension Arms and Pad Frame Rocker Arms for installing roof panels (see
Spec Sheet 8-11). See separate instructions about these and other options.
Operating Elevation: Maximum = 6000 ft [1828 m]
Operating Temperatures: 32° to 104° F [0° to 40° C]
Service Life:
This lifter is designed to have a service life of at least 20,000 lifting cycles, when used and
maintained as intended. Vacuum pads, filter elements and other wear-out items are excluded; see
MAINTENANCE and REPLACEMENT PARTS LIST for more information. For the D
ISPOSAL OF THE
L
IFTER
after its service life, see INTENDED USE.
ASME Standard BTH-1: Design Category "B", Service Class "0" (see www.powrgrip.com for more information)
!!-CE-!! Note: This symbol appears in the INSTRUCTIONS manual only when requirements of a CE Standard are different from requirements of
other standards that also apply to this vacuum lifter. CE requirements are mandatory in geographical areas where CE Standards apply, but may
be optional in other locations.
1
Load Capacity is based on a friction coefficient of 1; see MAINTENANCE: V ACUUM P AD M AINTENANCE : Friction Coefficient for
additional information.
Description: Designed for use with a crane or other hoisting equipment, the MRTALPR4-DC lifters employ
vacuum to hold a load for lifting, and they provide manual 180° rotation and mechanically assisted,
manual 90° tilt movements for load manipulation.
Model Number: MRTALPR4FS625DC MRTALPR4FS10TDC
Vacuum Pads: (Four, with #60 filter screen and replaceable sealing rings)
6" x 25" [15 cm x 64 cm] nom. dimensions,
standard rubber (Model VPFS625),
spring-mounted with 1/2" [12 mm] travel
10" [25 cm] nom. diameter,
standard rubber (Model VPFS10T),
spring-mounted with 1/4" [7 mm]
Pad Spread: (to outer edges)
Maximum: 36¼" x 92" [92 cm x 234 cm] 45¾" x 78¾" [116 cm x 200 cm]
Minimum: 18¼" x 92" [46 cm x 234 cm] 25¾" x 78¾" [65 cm x 200 cm]
Lifter Weight: 226 lbs [103 kg] 201 lbs [92 kg]
