Replacement parts list – Wood’s Powr-Grip MRTALPR4FS10TDC User Manual
Page 35
Rev 6.0/5-14
33
MRTALPR4-DC: #35057
REPLACEMENT PARTS LIST
Stock No.
Description
Qty.
97465HV
Pad Frame T-Arm Assembly w/VPFS10T Vacuum Pads (Option CF13CEO)
2
97465
Pad Frame T-Arm Assembly w/VPFS625 Vacuum Pads (Option CF13CEO)
2
97464
Pad Frame Extension Kit for Roof Panels (Option CF14CEO)
1
97463
Pad Frame Rocker Arms Set for Roof Panels (Option CF14CEO)
1
93221
Vacuum Pump - Diaphragm Type - 2.5-SCFM [71 liters/minute] - 12 V DC (Dynaflo)
1
66197BM
Dynaflo Pump Gasket & Flap Valves
2
66197AM
Dynaflo Pump Diaphragm Kit
2
66197AA
Dynaflo Pump Dual-Head Assembly
2
65442CA
Vacuum Hose - 1/4" [6.3 mm] OD - Red (approx. 120" [305 cm] in length)
1
65442AM
Vacuum Hose - 1/4" [6.3 mm] ID x 48" [122 cm] Length - Coiled - Green
2
65441
Vacuum Hose - 1/4" [6.3 mm] ID x 48" [122 cm] Length - Coiled - Red
2
65439AM
Vacuum Hose - 5/32" [4.0 mm] OD - Red (approx. 25" [64 cm] in length)
1
65439
Vacuum Hose - 5/32" [4.0 mm] OD - Blue (approx. 25" [64 cm] in length)
1
65429
Vacuum Hose - 1/4" [6.3 mm] OD - Blue (approx. 200" [508 cm] in length)
1
65211
Check Valve - 1/8 NPT
2
65011
Pad Spring - Tapered Type (for VPFS625 pads)
16
65010
Pad Spring - Coil Type (for VPFS10T pads)
4
64834
LED Indicator - 12 V DC - Green (aka, vacuum lift light)
1
64832
LED Indicator - 12 V DC - Blue - Small (aka, power light)
1
64752
Audio Alarm - 5-15 V DC - Panel Mount
1
64713AM
Battery Charger - 7 Amp - 240 V AC - Australian Type
1
64712AM
Battery Charger - 7 Amp - 100 / 120 V AC
1
64711AM
Battery Charger - 7 Amp - 240 V AC
1
64682
Battery - 1.5 V DC - AA Alkaline (for optional radio transmitter)
2
64665
Battery - 12 V DC - 18 Amp-Hours
1
64590
Battery Gauge
1
64460
Circuit Breaker - 15 A
1
64453CT
Circuit Board - Populated
1
64271
Strobe Light - 12 V DC - Amber (optional)
1
64269MA
Strobe Light - 12 V DC - Red
1
64238AA
Vacuum Switch - Digital
2
64233
Power Switch
1
64213
Push-Button Switch - Chrome (for apply, enable, and release buttons)
3
64199
Push-Button Switch - Red (for battery test button)
1
57389
Remote Control System Retrofit Kit (option)
1
—
Battery Connector - Twin Lead (for 18 amp-hour battery)
1
54107
Movable Pad Mount - 2-1/2" [63.5 mm] Tubing Size
4
53122
Pad Fitting - Elbow - 5/32" [4.0 mm] ID (for VPFS10T pads)
4
49724TT
Sealing Ring Insert - Model VIFS10T (for VPFS10T pads)
4
49723BT
Sealing Ring Insert - Model VIFS625 (for VPFS625 pads)
4
49672T
Vacuum Pad - Model VPFS10T / 10" [25 cm] Diameter - w/Replaceable Sealing Ring
4
49150
End Plug - 2 1/2" x 2 1/2" x 1/4" [63.5 mm x 63.5 mm x 6.4 mm] Tubing Size
3
49122
End Plug - 2" x 2" x 1/4" [50.8 mm x 50.8 mm x 6.4 mm] Tubing Size
4
29353
Pad Cover (for VPFS10T pads)
4
16131
Element for Air Filter
2
16057
Quick Connector - 1/8 FNPS - Male End
4
16056
Quick Connector - 1/8 FNPS - Female End
8
15920
Vacuum Gauge - 1/8 NPT - CBM Type - w/Panel Mount Bracket
2
15792AM
Rotation or Tilt Release Lever Knob
2
15632
Pad Filter Screen - Small (for VPFS10T pads)
4
15630
Pad Filter Screen - Large (for VPFS625 pads)
4
15310AM
Pad Fitting - Push-In Swivel Elbow - 1/4 Male-NPT to 3/8" OD Hose Size (for VPFS625 pads)
4
13530
Cotterless Hitch Pin - 1/2" x 3 1/2" [13 mm x 89 mm]
6
11726AM
Clamp Collar - 2.157-18 Thread - 1-Piece
1
10906PM
Shoulder Bolt - Socket Head - 3/8" x 1" x 5/16-18 Thread (for mounting VPFS625 pads)
16
10900
Shoulder Bolt - Socket Head - 5/16" x 1/2" x 1/4-20 Thread (for mounting VPFS10T pads)
24
SERVICE ONLY WITH IDENTICAL REPLACEMENT PARTS
SUPPLIED BY OR APPROVED BY WOOD'S POWR-GRIP CO., INC.
