Wood’s Powr-Grip MRTALPR4FS10TDC - Manual (Page 16)

Rev 6.0/5-14 14 MRTALPR4-DC: #35057
In addition to the sliding / movable pad mounts, T-arm assemblies offer a second means of
adjusting the position of vacuum pads: The bolts connecting the cross member to the extension
arm on each T-arm assembly may be removed, allowing you to reposition the cross member.
This allows you to align the pads precisely on the 2 T-arm assemblies, for example, in order to
attach the lifter on cladding panel profiles with high contours and/or narrow spacing between
contours. Be sure to tighten the bolts securely each time after you reposition a cross member
on its extension arm.
