Rev 6.0/5-14 17 MRTALPR4-DC: #35057
T
O
L
IFT AND
M
OVE THE
L
OAD
Positioning the Lift Bar
WARNING: Lift bar must be oriented vertically to lift
load.
Never lift the load from a flat position with the lift bar latched parallel
to the load. Always disengage the tilt latch (see T
O
T
ILT THE
L
OAD
to
follow) and raise the lift bar to a vertical orientation before attempting to lift.
Interpreting the Warning Buzzer and Lights
A lifter's Load Capacity is rated at a vacuum level of 16" Hg [-54 kPa] (see SPECIFICATIONS).
After the lifter has attained this level, the low vacuum warning buzzer and the red strobe light
turn
off automatically, whereas the green vacuum lift light turns on automatically, to signal that
the lifter is ready to lift the maximum load weight. As vacuum continues to increase, the
vacuum pump also turns off, to conserve battery energy.
WARNING: Never attempt to lift load unless green lift light is illuminated.
Do not attempt to lift the load unless the lift light is illuminated; such an attempt could result in a
load release and possible injury to the operator.
Monitoring Vacuum Indicators
The vacuum lift light and both vacuum gauges must remain completely visible to the operator, so
that they can be monitored throughout the entire lift.
WARNING: Vacuum indicators must be visible to operator throughout entire
lift.
If the vacuum system experiences leakage while the lifter is attached to the load, the vacuum
pump turns on and off automatically, as required to maintain sufficient vacuum for lifting the
maximum load weight. Under normal conditions, such intermittent cycling of the pump is no
cause for alarm.
However, if vacuum decreases significantly, the lift light turns
off and the low vacuum warning
buzzer turns on , to signal the reduction in vacuum to the operator. If this occurs while you are
lifting a load, make sure both vacuum gauges show a vacuum level of 16" Hg [-54 kPa] or
higher. If not, move away and stay clear of the load until it can be lowered to the ground or a
stable support.
WARNING: Stay clear of any suspended load while vacuum level is lower than
16" Hg [-54 kPa].
Discontinue lifter use until the cause of the vacuum loss can be determined. If the pump runs
at intervals of ten minutes or less while the lifter is attached to clean, smooth, nonporous
materials, the leakage is likely to be in the vacuum system. In this event, perform the V
ACUUM
T
EST
(see MAINTENANCE) and inspect the vacuum pads for damage (see MAINTENANCE: V
ACUUM
P
AD
M
AINTENANCE
: Inspection). If the vacuum loss cannot be remedied immediately, perform
inspection and maintenance as needed to identify and correct any deficiency before resuming
normal operation of the lifter.
