IV - 11
(4) Remove the paper feed chassis unit.
Figure 4.23
1.13 Separation Pad Assy
(1) Remove the paper pick-up roller assy and roller collar. (Refer to subsection 1.22)
(2) Remove the separation pad assy by pulling it out from the paper feed guide upper.
Figure 4.24
(3) Remove the spring from the separation pad assy.
Figure 4.25
Separation pad assy
Separation pad spring
Paper feed chassis unit
Paper feed guide upper
Paper pick-up roller assy
Paper pick-up roller collars
Separation pad assy
