Chapter 1 Introduction
EB1004 BAK is a stand-alone, non-PC based DVR unit that provides real-time
monitoring and digital recording of surveillance video. Up to four video cameras and
four sensor devices can be hooked up to this DVR unit. It is also equipped with an
output relay that allows connection of an alarm device.
Surveillance, digital recording and playback are controlled through the front panel
buttons. Users can connect EB-1004 BAK to a PC to trace back video files, and even
save image as both BMP and AVI files. With the on-screen-display (OSD) menu, you
can customize video recording settings, sensor and alarm settings, password
protection, hard drive recycling, and more.
Surveillance video is recorded in high-quality Motion-JPEG format. Two recording
modes are available. EACH mode records video from each video camera in 640 x 224
resolution at 7.5 fps. QUAD mode records video in 320 x 112 resolution and up to 30
fps/25 fps (NTSC/PAL).
EB1004 BAK provides a removable hard disk bay for installing one hard drive and
an internal slot for installing a second hard drive.
1.1 Features and Specifications
• Non-PC stand-alone security digital video recorder
• 4 composite video inputs and 1 composite output
• VGA output for LCD monitor display
• Front panel buttons and OSD control
• Motion-JPEG video compression
• Factory defaulted to NTSC or PAL
• Supports 2 hard drives (not included)
