8
1.4.2 Install the Hard Drive in a Removable Case
1. After unlock the removable hard disk drawer,
remove the removable hard drive drawer
from the case.
2. Remove the upper cover of the drawer.
3. Connect the power connector to the hard
drive as the right picture shows.
4. Connect the hard disk connector into the
inner tray’s slot.
5. Close the upper cover. Slide the drawer into
the removable hard drive case, and lock the
drawer.
6. Power on the unit to see the LED indicators on the front side of the removable
hard disk holder. If the LED indicators light up, you may use the hard disk.
