52
lux.
¾ 23x MODEL
The shutter speed is adjustable on 23x MODEL. With the slowest shutter
speed, users can see objects in a dark environment under 0.2 lux; or see a
smooth video image with a higher shutter speed. The options are from <1/2>
to <1/60>.
♦ ANGLE ADJUSTER
The item is for adjusting the camera view angle. The ranges of view angle
are changed in different FLIP mode: the angle ranges from -1
0° to +100°
with ME FLIP and FLIP OFF modes, and from -10° ~ +190° with
IMAGE FLIP mode. With IMAGE FLIP function, users are able to
adjust the view angle from -10° ~ +190° to catch the true horizontal
line.
♦ RESET
Select this item to reset all the camera parameters of SETUP MENUs to the
factory dfault.
♦ EXIT
Exit the SETUP MENU1 and go back to MAN MENU.
B-3-9 SETUP MENU2 (18x MODEL Only)
The Aperture and Mask Display settings can be configured under SETUP
MENU2.
ANGLE ADJUSTER
ADJUST MIN ANGLE -10 DEG
ADJUST M
AX ANGLE 100 DEG
EXIT+SET YES
