48
3200K Base mode
♦ OUTDOOR
5800K Base mode
♦ ATW
Auto Tracing White Balance mode. The dome taking out the signals in a
screen in the range from 2000K to 10000K.
♦ MANUAL
In this mode, users can change the White Balance value manually; R gain
and B gain are adjustable and range from 0 to 128.
¾ 22x MODEL / 23x MODEL
♦ AUTO
In this mode, white balance works within its colour temperature range and
calculates the best-fit white balance.
♦ MANUAL
In this mode, users can change the White Balance value manually; adjustable
R gain and B gain range from 0 to 99.
B-3-7 ID DISPLAY
Users are allowed to choose whether the dome ID will be displayed on monitor to
identify the domes.
♦ ON
Display the ID address of the selected dome on the right bottom of the
WBC MENU
R GAIN 50
B GAIN 50
WBC MENU
R GAIN 50
B GAIN 50
