43
18x MODEL 22x MODEL/23x MODEL
B-3-1 DEFAULT CAMERA
The “DEFAULT CAMERA” is used to restore the camera settings (e.g.
Backlight/Focus/AE//WBC/Aperture). Once any one of the items is modified, the
setting will become automatically. Select for this item to recall the
mentioned camera parameters.
B-3-2 BACKLIGHT
The Backlight compensation function prevents the center object from being too
dark in surroundings where excessive light is behind the center object.
¾ 18x MODEL
Turn this item ; the center object will be brightened in contrast to the edge
of the picture (where a backlight would most likely be located).
¾ 22x MODEL / 23x MODEL
The Backlight Compensation Level ranges from 000 to 100.
NOTE: On 18x MODEL, the Aperture function is provided in
“SETUP MENU2”, instead of “DEFAULT CAMERA”.
NOTE: If this function is enabled, the WDR function (for 23x
MODEL only) will be disabled automatically. For details, refer
to section B-1-19 WDR Setting.
BLC LEVEL
LEVEL 20
EXIT
YES
MAIN PAGE 1
DEFAULT CAMERA OFF
BACKLIGHT OFF
FOCUS
AUTO
APERTURE AUTO
AE MODE
AUTO
WBC MODE AUTO
ID DISPLAY ON
SETUP MENU ENTER
MAIN PAGE 1
DEFAULT CAMERA OFF
BACKLIGHT OFF
FOCUS
AUTO
AE MODE AUTO
WBC MODE AUTO
ID DISPLAY ON
SETUP MENU1
SETUP MENU2
