4.7. Volume measurement
This measurement allows calculating the volume of
solids expressed in m
3
, in
2
or ft
3
1. With the instrument in stand-by, press the key
to select the desired type of reference (see § 4.2)
2. Press the key twice to enter the Area/Volume
measuring section. The symbol “ “ appears on
the display with side “higher” flashing
3. Press the key or the side MEAS key to
perform the first measurement (length) of the
surface (see Fig. 8). The corresponding value
appears on the first partial display. The symbol “
“
appears on the display with side “1” flashing
4. Press the key or the side MEAS key to
perform the second measurement (width) of the
surface (see Fig. 8). The corresponding value
appears on the second partial display. The value of
the corresponding area is shown on the resulting
display. The symbol “
“ appears on the display
with side “2” flashing
5. Press the key or the side MEAS key again to
perform the third measurement (height) (see Fig.
8). The total value of volume is shown on the main
resulting display
6. Measuring result is automatically saved in the
instrument's memory
Fig. 8: Example of volume measurement
