HT instruments iDM70 - Manual (Page 13)

iDM70
EN - 12
4.6. Area measurement
This measurement allows calculating the area of
surfaces expressed in m
2
, in
2
or ft
2
1. With the instrument in stand-by, press the key
or the side MEAS key to select the desired type of
reference (see § 4.2)
2. Press the key to enter the Area/Volume
measuring section. The symbol “ “ appears on
the display with side “1” flashing
3. Press the key or the side MEAS key to
perform the first measurement (length) of the
surface concerned (see Fig. 7). The corresponding
value appears on the first partial display. The
symbol “
“ appears on the display with side “2”
flashing
4. Press the key or the side MEAS key to
perform the second measurement (width) of the
surface concerned (see Fig. 7). The corresponding
value appears on the second partial display, while
the (up-to-date) total value of the area appears on
the resulting display
5. Measuring result is automatically saved in the
instrument's memory
Fig. 7: Example of area measurement
