RECOMMENDED BRINE TANK
APPROXIMATE
PIPE SIZE
MINERAL TANK
SIZE
SALT STORAGE SHIPPING WEIGHT-TOP MOUNT
MODEL
(INCHES)
(INCHES)
(INCHES)
( LBS)
SINGLE
TWIN
H200-240
2
24 X 72
24 X 50
715
674
1325
H200-300-24
2
24 X 72
24 X 50
715
776
1529
H200-300-30
2
30 X 72
24 X 50
670
1059
2064
H200-450-30
2
30 X 72
30 X 50
1,110
1333
2593
H200-450-36
2
36 X 72
30 X 50
1,110
1393
2653
H200-600
2
36 X 72
39 X 48
1,640
1751
3426
H200-750
2
42 X 72
42 X 60
2,580
2535
4954
H200-900
2
42 X 72
50 X 60
4,130
2922
5750
H200-1200
2
48 X 72
50 X 60
4,130
3600
6900
Mineral tank sizes shown are with polyglass tanks.
RATED CAPACITY
FLOW RATES (gpm)
RESIN
LOW SALT
MEDIUM SALT
HIGH SALT
BKW
MODEL
CU.FT.
GRAINS/LBS
GRAINS/LBS
GRAINS/LBS
15 PSI
25 PSI
GPM
H200-240
8
152,000/48
224,000/80
256,000/120
77
100
12
H200-300-24
10
190,000/60
280,000/100
320,000/150
75
97
12
H200-300-30
10
190,000/60
280,000/100
320,000/150
92
120
20
H200-450-30
15
285,000/90
420,000/150
480,000/225
88
113
20
H200-450-36
15
285,000/90
420,000/150
480,000/225
100
130
30
H200-600
20
380,000/120
560,000/200
640,000/300
97
126
30
H200-750
25
475,000/150
700,000/250
800,000/375
106
137
40
H200-900
30
570,000/180
840,000/300
960,000/450
104
130
40
H200-1200
40
760,000/240
1,120,000/400
1,280,000/600
105
135
50
1. Steel tank design configurations available up through 60” tank diameters. Consult factory for details.
OPERATING CONDITIONS
1. Water Pressure 30 - 100 psi.
2. Water temperature is not to exceed 110°F and the unit cannot be subject to freezing conditions. Consult factory for higher water temperature applications.
3. Limit of 2 ppm of Ferrous Iron. Add 3 grains per gallon of hardness for each ppm of iron present.
4. Flex connectors and vacuum breakers are required when using the PolyGlass Composite mineral tanks.
5. Backwash flow rates are calculated at 4 gpm per sq. ft. of bed area and rounded off based on 50ºF water temperature.
6. Refer to Hellenbrand Bulletin 2050 “Flow Rates and Soft Water Quality (Hardness Leakage) if your application requires that levels of hardness leakage do not exceed “x”.
H200-300 89.4 86.7 83.1 85.4 24x72
24x50
H200-300-30
86.2 83.5 79.9 82.2 30x72
24x50
H200-450 86.2 83.5 79.9 82.2 30x72
30x50
H200-600 87.2 84.5 80.9 83.2 36x72
39x48
H200-750 104.5 101.8 98.2 100.5 42x72
42x60
H200-900 104.5 101.8 98.2 100.5 42x72
50x60
H200-1200 104.5 101.8 98.2 100.5 48x72
50x60
SYSTEM OUTLET
INLET
DRAIN MINERAL BRINE
MODEL
HEIGHT HEIGHTS HEIGHTS HEIGHTS TANK TANK
H200 Physical Specifications
H200 Capacity Ratings
H200 Series Top Mount Dimensions
H200-300-SM 95.6 54.6 51 53.3 24x72 24x50
H200-300-30-SM 94.6 54.6 51 53.3 30x72 24x50
H200-450-SM 94.6 54.6 51 53.3 30x72 30x50
H200-600-SM 95.3 54.6 51 53.3 36x72 39x48
H200-750-SM 100.9 54.6 51 53.3 42x72 42x60
H200-900-SM 100.9 54.6 51 53.3 42x72 50x60
H200-1200-SM 100.9 54.6 51 53.3 48x72 50x60
All dimensions ±2” and are subject to change without notice. Use as reference only.
Call factory for optional tank & dimensional configurations.
Product Improvement designs are subject to change without notice.
SYSTEM OUTLET INLET
DRAIN
MINERAL
BRINE
MODEL
HEIGHT HEIGHTS HEIGHTS HEIGHTS TANK
TANK
H200 Series Side Mount Dimensions
