GASS-2040 User Manual | Original Instructions
APPENDIX A
Specifications
MAXIMUM SAMPLE FLOW RATE:
0 TO 10 LITER/MIN
MAXIMUM INLET SAMPLE TEMPERATURE:
250
°F W/SST FILTER
230
°F W/KYNAR FILTER
MAXIMUM GAS SAMPLE WATER VAPOR CONTENT:
70%
OUTLET SAMPLE DEW POINT:
26
°F (-4°C) at 10 L/MIN
(With GS2040-PD200KA dryer)
12
°F (-12°C) at 5 L/MIN
-12
°F (-25°C) at 2 L/MIN
36
°F (2°C) at 10 L/MIN
(With GS2040-PD100KA dryer)
26
°F (-4°C) at 5 L/MIN
6
°F (-15°C) at 2 L/MIN
(With GS2040-50KA dryer)
42
°F(5°C) at 10 L/MIN
SOLUBLE GAS REMOVAL RATES:
NO, NO2, SO2 0% loss
CO, CO2
0% loss
H2S, HCl
0% loss
MAXIMUM GAS SAMPLE INLET PRESSURE:
10 PSIG
MINIMUM GAS SAMPLE INLET PRESSURE:
- WITHOUT PURGE EDUCTOR OPTION:
5" H2O VACUUM
- WITH PURGE EDUCTOR OPTION:
10” H2O VACUUM
GAS SAMPLE INLET FITTINGS:
1/4" or 3/8" TUBING FITTINGS
GAS SAMPLE OUTLET FITTINGS:
1/4" or 3/8" TUBING FITTINGS
AIR REQUIREMENTS:
PURGE AIR -40
°C DEW POINT
MAXIMUM ONE (1) CFM
-OPTIONAL PURGE EDUCTOR
MAXIMUM THREE (3) CFM
ELECTRICAL REQUIREMENTS:
950 Watts @ 115V ±10% or 230V ±10%,
50/60Hz, 10A/5A
FUSE:
- FUSE BLOCK
1.25” X 0.25” GLASS FUSE
- INLINE FUSE HOLDER (PLC)
5mm X 20mm 1.0A FAST-BLOW FUSE
ENCLOSURE:
NEMA 4X, STAINLESS STEEL
DIMENSIONS:
20”W x 40”H x 10”DEEP
OPERATING ENVIRONMENT:
-20
°C TO 40°C AMBIENT TEMP.
0 TO 95% R.H.
Altitude - up to 2000m
