4. CONFIGURATIONS
4.1 Setting the Dip Switches
Before closing cover, the mode must be selected using the dip switches.
Important: Setting the dip switches incorrectly will cause the
the humidistat to malfunction.
Dip Switch Settings
Dip1 Dip2 Dip3 Dip4
ON OFF OFF OFF
ON OFF OFF ON
Tab. 4.a
4.2 Setting Parameters
The parameters for all operating modes feature a default value. These
values can be restored by running the “Factory set” operation. See the
table of parameters for details of the default values and settings.
Initially at least the following parameters need to be checked/set:
SET POINT: • erent set points
are used. To set these, access (SET button – 5 seconds) the mode
for setting the parameters and set the corresponding values.
For the current mode only, the value can be accessed directly
set point for humidity control •
–
–
Clock, • TIME BANDS Prg/ (clock): Press the corresponding button
to display and if necessary set the default duration of the change mode
timer, display or set the RTC clock and set the Day and Night time bands.
rtC clock hh:mm
SLP manual changeover duration def. 8 hours
dAy start day band def. 08:00
nIt start night band def. 20:00
Once having displayed the desired parameter using the UP/
Edit the value using the UP/DOWN buttons and then press SET.
To
exit the menu, press the PRG button again
:
Select parameter rtC using PRG/CLOCK and set the value using the •
DOWN button
When reaching 00:00 using the DOWN button the function will be
•
.
the operating mode is always daytime,
and consequently only the daytime set points are used, the night
settings are only used when the NIGHT button is pressed, manually
changing mode.
The same is true for models without the RTC function.
When the time bands are set, the CLOCK symbol is shown on the
display.
PARAMETERS:
• check/set the other parameters (dIF, dS1,...) based on
the mode used.
Note:
Note: If AUTO humidity mode is enabled, the humidity setpoint
is reduced to 10% when the outdoor temperature is greater than
50° F. Disable AUTO for operation in warm outdoor temperatures.
set of parameters will be loaded by the GFX50 when changing the
7
4.3 AUTO humidity control
In addition to the modes featured by the control algorithms, the humidity
can be controlled automatically, based on the reading of the outside
temperature sensor. The aim of this type of control is to simplify the
setting of the GFX50, changing the humidity control according to the
outside environmental conditions and therefore minimize the discomfort
of the user when moving into/out of the air-conditioned environment.
This operating mode is selected by setting parameter AUT.
According to the level set using the up/down buttons, with a value from
To disable this operating mode, in the parameters menu set the value of
Aut = 0.
temperature sensor is installed.
code description of the parameter range def. UOM
AUt
Humidity set point level compensated according to the outside temperature
If set to OFF, the mode is disabled.
Setting one of the levels shown in the table, the controller independently sets a humidity set point in relation to
the outside temperature measurement.
OFF
1H to 7H
OFF -
Table: humidity set point according to the setting of AUT (outside temperature)
Level Below: -23 °C -23 °C to -17 °C -17 °C to -12 °C -12 °C to -6 °C -6 °C to -1 °C -1 °C to 4 °C 4 °C to 10 °C Above: 10 °C
Level Below: 9 °F -9 °F to 1 °F 1 °F to 10 °F 10 °F to 21 ° 21 °F to 30 °F 30°F to 39° 39°F to 50 °F Above: 50 °F
1 10% 10% 10% 10% 15% 20% 25% 25%
2 10% 10% 10% 15% 20% 25% 30% 30%
3 10% 10% 15% 20% 25% 30% 35% 35%
4 10% 15% 20% 25% 30% 35% 40% 40%
5 10% 20% 25% 30% 35% 40% 45% 45%
6 10% 25% 30% 35% 40% 45% 45% 45%
7 10% 30% 35% 40% 45% 45% 45% 45%
Tab. 4.b
