F
8
FIG. 42 TAILLIGHT
1 5PS−84710−00 TAILLIGHT UNIT ASSY 1 1
2 1A2−84714−41 .BULB (12V−21/5W) 1 1
3 5PS−84721−00 .LENS, TAILLIGHT 1 1
4 47X−84723−00 .GASKET, TAIL LENS 1 1
5 5PS−84735−00 .CORD ASSY 1 1
6 90480−14323 GROMMET 2 2
7 90201−06071 WASHER, PLATE 2 2
8 90387−066Y6 COLLAR 2 2
9 95307−06600 NUT 2 2
10 3Y6−85130−02 REAR REFLECTOR ASSY 1 1
11 95707−05500 NUT, FLANGE 1 1
PART NO. DESCRIPTION REMARKS
REF.
NO.
5PS1 5PS2
