Yamaha TDM900P - Manual (Page 19)

B
14
FIG. 8 OIL PUMP
55 90109−06056 BOLT 1 1
56 5PS−13317−00 PLATE, BAFFLE 1 1
57 90110−06018 BOLT, HEXAGON SOCKET HEAD 2 2
58 5PS−21761−00 GAUGE, LEVEL 1 1
59 93210−21190 O−RING 1 1
60 5PS−21750−00 OIL TANK ASSY 1 1
61 95827−06014 BOLT, FLANGE 3 3
62 90445−11026 HOSE 1 1
63 90467−10008 CLIP 2 2
64 5JX−24188−00 MOLD, FUEL TANK 1 1
65 5BM−21652−00 PROTECTOR 1 1
66 5BM−21268−00 SEAL 2 2
67 90387−085N0 COLLAR 1 1
68 93210−10096 O−RING 1 1
69 90387−106W6 COLLAR 1 1
70 93210−12790 O−RING 1 1
71 90387−06761 COLLAR 1 1
72 93210−07135 O−RING 1 1
73 90387−130W6 COLLAR 1 1
74 93210−15566 O−RING 1 1
PART NO. DESCRIPTION REMARKS
REF.
NO.
5PS1 5PS2
