128
○ ○
MIDI Data Format / MIDI-Datenformat / Format des donées MIDI / Formato de datos MIDI
Parameter Base Address
Model ID = 4CParameter ChangeAddress(H)(M)(L)DescriptionCVP MIDI000000SystemSYSTEM00007DDrum Setup Reset00007EXG System On00007FReset All ParametersEFFECT 1020100Effect1(Reverb,Chorus,Variation )DRUM301800Drum Setup 1311800Drum Setup 2Note: The CVP 79A/69/69A/59S contain 3 drum setups (1 Preset Drum &Drum Setup 1, 2). Preset Drum being the preset drum setup, its
parameters cannot be rewritten.AddressParameter3n 0B 00note number 133n 0C 00note number 14::3n 5B 00note number 91m MIDI Parameter Change table ( SYSTEM )AddressSizeDataParameterDescriptionDefault value(H)(H)(H)(H)00 00 0040000 - 07FFMASTER TUNE-102.4 - +102.3[cent]00 04 00 00011st bit3-0→bit15-12-400022nd bit3-0→bit11-8033rd bit3-0→bit7-44th bit3-0→bit3-004100 - 7FMASTER VOLUME0 - 1277F06128 - 58TRANSPOSE-24 - +24[semitones]40071——7DnDRUM SETUP RESETn=Drum setup number7E00XG SYSTEM ON00=XG sytem ON7F00RESET ALL PARAMETERS00=ON (receive only)TOTAL SIZE07MIDI Parameter Change table ( EFFECT 1)Refer to the “Effect MIDI Map” for a complete list of Reverb, Chorus and Variation type numbers.
Refer to the “Effect Parameter List” for a detailed description of each parameter.AddressSizeDataParameterDescriptionDefault value(H)(H)(H)(H)02 01 00200-7FREVERB TYPE MSBRefer to Effect MIDI Map01(=HALL1)00-7FREVERB TYPE LSB00 : basic type0002100-7FREVERB PARAMETER 1Refer to Effect Parameter ListDepends on reverb type03100-7FREVERB PARAMETER 2Refer to Effect Parameter ListDepends on reverb type04100-7FREVERB PARAMETER 3Refer to Effect Parameter ListDepends on reverb type05100-7FREVERB PARAMETER 4Refer to Effect Parameter ListDepends on reverb type06100-7FREVERB PARAMETER 5Refer to Effect Parameter ListDepends on reverb type07100-7FREVERB PARAMETER 6Refer to Effect Parameter ListDepends on reverb type08100-7FREVERB PARAMETER 7Refer to Effect Parameter ListDepends on reverb type09100-7FREVERB PARAMETER 8Refer to Effect Parameter ListDepends on reverb type0A100-7FREVERB PARAMETER 9Refer to Effect Parameter ListDepends on reverb type0B100-7FREVERB PARAMETER 10Refer to Effect Parameter ListDepends on reverb type0C100-7FREVERB RETURN-∞dB...0dB...+6dB(0...64...127)400D101-7FREVERB PANL63...C...R63(1...64...127)40TOTAL SIZE0E02 01 10100-7FREVERB PARAMETER 11Refer to Effect Parameter ListDepends on reverb type11100-7FREVERB PARAMETER 12Refer to Effect Parameter ListDepends on reverb type12100-7FREVERB PARAMETER 13Refer to Effect Parameter ListDepends on reverb type13100-7FREVERB PARAMETER 14Refer to Effect Parameter ListDepends on reverb type14100-7FREVERB PARAMETER 15Refer to Effect Parameter ListDepends on reverb type15100-7FREVERB PARAMETER 16Refer to Effect Parameter ListDepends on reverb typeTOTAL SIZE602 01 20200-7FCHORUS TYPE MSBRefer to Effect MIDI Map41(=CHORUS1)00-7FCHORUS TYPE LSB00 : basic type0022100-7FCHORUS PARAMETER 1Refer to Effect Parameter ListDepends on chorus type23100-7FCHORUS PARAMETER 2Refer to Effect Parameter ListDepends on chorus type24100-7FCHORUS PARAMETER 3Refer to Effect Parameter ListDepends on chorus type25100-7FCHORUS PARAMETER 4Refer to Effect Parameter ListDepends on chorus type26100-7FCHORUS PARAMETER 5Refer to Effect Parameter ListDepends on chorus type27100-7FCHORUS PARAMETER 6Refer to Effect Parameter ListDepends on chorus type28100-7FCHORUS PARAMETER 7Refer to Effect Parameter ListDepends on chorus type29100-7FCHORUS PARAMETER 8Refer to Effect Parameter ListDepends on chorus type2A100-7FCHORUS PARAMETER 9Refer to Effect Parameter ListDepends on chorus type2B100-7FCHORUS PARAMETER 10Refer to Effect Parameter ListDepends on chorus type2C100-7FCHORUS RETURN-∞dB...0dB...+6dB(0...64...127)402D101-7FCHORUS PANL63...C...R63(1...64...127)402E100-7FSEND CHORUS TO REVERB-∞dB...0dB...+6dB(0...64...127)00TOTAL SIZE0F02 01 30100-7FCHORUS PARAMETER 11Refer to Effect Parameter ListDepends on chorus type31100-7FCHORUS PARAMETER 12Refer to Effect Parameter ListDepends on chorus type32100-7FCHORUS PARAMETER 13Refer to Effect Parameter ListDepends on chorus type33100-7FCHORUS PARAMETER 14Refer to Effect Parameter ListDepends on chorus type34100-7FCHORUS PARAMETER 15Refer to Effect Parameter ListDepends on chorus type35100-7FCHORUS PARAMETER 16Refer to Effect Parameter ListDepends on chorus typeTOTAL SIZE602 01 40200-7FVARIATION TYPE MSBRefer to Effect MIDI Map05(=DELAY L,C,R)00-7FVARIATION TYPE LSB00 : basic type0042200-7FVARIATION PARAMETER 1 MSBRefer to Effect Parameter ListDepends on variation type00-7FVARIATION PARAMETER 1 LSBRefer to Effect Parameter ListDepends on Variation type Pages: 1 … 129 130 131 132 133 … 163 wrong Brand wrong Model non readable See also other documents in the category Yamaha Synthesizers: PSR-1100 (170 pages) PSR-1100 (176 pages) PSR-290 (98 pages) YPT-310 (90 pages) CLP-230 (90 pages) CLP-230 (89 pages) YPT-300 (84 pages) DGX-205 (90 pages) MM8 EU (116 pages) MOX8 (14 pages) MOTIF XS8 (320 pages) PSR-4600 (30 pages) PSR-32 (20 pages) PSR-530 (130 pages) PSR-510 (77 pages) PSR-330 (90 pages) PSR-3500 (84 pages) PSR-500 (47 pages) PSR-41 (13 pages) PSR-4000 (165 pages) PSR-38 (55 pages) PSR-520 (102 pages) PSR-340 (128 pages) PSR-40 (16 pages) PSR-36 (28 pages) PSR-48 (45 pages) PSR-420 (73 pages) PSR-420 (75 pages) PSR-300m (39 pages) PSR-37 (30 pages) PSR-4500 (48 pages) PSR-50 (32 pages) PSR-410 (61 pages) PSR-540 (161 pages) PSR-540 (160 pages) PSR-31 (20 pages) CLP-100 (11 pages) CLP-122S (31 pages) CLP-123 (30 pages) CLP-30 (11 pages) CLP-300 (11 pages) CLP-250 (17 pages) CLP-260 (19 pages) CLP-280 (124 pages) CLP-550 (19 pages) Sitemap
Parameter Base Address
Model ID = 4C
Parameter Change
Address
(H) (M) (L) Description
CVP MIDI 00 00 00 System
SYSTEM 00 00 7D Drum Setup Reset
00 00 7E XG System On
00 00 7F Reset All Parameters
EFFECT 1 02 01 00 Effect1(Reverb,Chorus,Variation )
DRUM 30 18 00 Drum Setup 1
31 18 00 Drum Setup 2
Note: The CVP 79A/69/69A/59S contain 3 drum setups (1 Preset Drum &
Drum Setup 1, 2). Preset Drum being the preset drum setup, its
parameters cannot be rewritten.
Address Parameter
3n 0B 00 note number 13
3n 0C 00 note number 14
: :
3n 5B 00 note number 91
m
MIDI Parameter Change table ( SYSTEM )
Address Size Data Parameter Description Default value
(H) (H) (H) (H)
00 00 00 4 0000 - 07FF MASTER TUNE -102.4 - +102.3[cent] 00 04 00 00
01 1st bit3-0 → bit15-12 -400
02 2nd bit3-0 → bit11-8
03 3rd bit3-0
→
bit7-4
4th bit3-0 → bit3-0
04 1 00 - 7F MASTER VOLUME 0 - 127 7F
06 1 28 - 58 TRANSPOSE -24 - +24[semitones] 40
07 1 — —
7D n DRUM SETUP RESET n=Drum setup number
7E 00 XG SYSTEM ON 00=XG sytem ON
7F 00 RESET ALL PARAMETERS 00=ON (receive only)
TOTAL SIZE 07
MIDI Parameter Change table ( EFFECT 1)
Refer to the “Effect MIDI Map” for a complete list of Reverb, Chorus and Variation type numbers.
Refer to the “Effect Parameter List” for a detailed description of each parameter.
Address Size Data Parameter Description Default value
(H) (H) (H) (H)
02 01 00 2 00-7F REVERB TYPE MSB Refer to Effect MIDI Map 01(=HALL1)
00-7F REVERB TYPE LSB 00 : basic type 00
02 1 00-7F REVERB PARAMETER 1 Refer to Effect Parameter List Depends on reverb type
03 1 00-7F REVERB PARAMETER 2 Refer to Effect Parameter List Depends on reverb type
04 1 00-7F REVERB PARAMETER 3 Refer to Effect Parameter List Depends on reverb type
05 1 00-7F REVERB PARAMETER 4 Refer to Effect Parameter List Depends on reverb type
06 1 00-7F REVERB PARAMETER 5 Refer to Effect Parameter List Depends on reverb type
07 1 00-7F REVERB PARAMETER 6 Refer to Effect Parameter List Depends on reverb type
08 1 00-7F REVERB PARAMETER 7 Refer to Effect Parameter List Depends on reverb type
09 1 00-7F REVERB PARAMETER 8 Refer to Effect Parameter List Depends on reverb type
0A 1 00-7F REVERB PARAMETER 9 Refer to Effect Parameter List Depends on reverb type
0B 1 00-7F REVERB PARAMETER 10 Refer to Effect Parameter List Depends on reverb type
0C 1 00-7F REVERB RETURN - ∞ dB...0dB...+6dB(0...64...127) 40
0D 1 01-7F REVERB PAN L63...C...R63(1...64...127) 40
TOTAL SIZE 0E
02 01 10 1 00-7F REVERB PARAMETER 11 Refer to Effect Parameter List Depends on reverb type
11 1 00-7F REVERB PARAMETER 12 Refer to Effect Parameter List Depends on reverb type
12 1 00-7F REVERB PARAMETER 13 Refer to Effect Parameter List Depends on reverb type
13 1 00-7F REVERB PARAMETER 14 Refer to Effect Parameter List Depends on reverb type
14 1 00-7F REVERB PARAMETER 15 Refer to Effect Parameter List Depends on reverb type
15 1 00-7F REVERB PARAMETER 16 Refer to Effect Parameter List Depends on reverb type
TOTAL SIZE 6
02 01 20 2 00-7F CHORUS TYPE MSB Refer to Effect MIDI Map 41(=CHORUS1)
00-7F CHORUS TYPE LSB 00 : basic type 00
22 1 00-7F CHORUS PARAMETER 1 Refer to Effect Parameter List Depends on chorus type
23 1 00-7F CHORUS PARAMETER 2 Refer to Effect Parameter List Depends on chorus type
24 1 00-7F CHORUS PARAMETER 3 Refer to Effect Parameter List Depends on chorus type
25 1 00-7F CHORUS PARAMETER 4 Refer to Effect Parameter List Depends on chorus type
26 1 00-7F CHORUS PARAMETER 5 Refer to Effect Parameter List Depends on chorus type
27 1 00-7F CHORUS PARAMETER 6 Refer to Effect Parameter List Depends on chorus type
28 1 00-7F CHORUS PARAMETER 7 Refer to Effect Parameter List Depends on chorus type
29 1 00-7F CHORUS PARAMETER 8 Refer to Effect Parameter List Depends on chorus type
2A 1 00-7F CHORUS PARAMETER 9 Refer to Effect Parameter List Depends on chorus type
2B 1 00-7F CHORUS PARAMETER 10 Refer to Effect Parameter List Depends on chorus type
2C 1 00-7F CHORUS RETURN - ∞ dB...0dB...+6dB(0...64...127) 40
2D 1 01-7F CHORUS PAN L63...C...R63(1...64...127) 40
2E 1 00-7F SEND CHORUS TO REVERB - ∞ dB...0dB...+6dB(0...64...127) 00
TOTAL SIZE 0F
02 01 30 1 00-7F CHORUS PARAMETER 11 Refer to Effect Parameter List Depends on chorus type
31 1 00-7F CHORUS PARAMETER 12 Refer to Effect Parameter List Depends on chorus type
32 1 00-7F CHORUS PARAMETER 13 Refer to Effect Parameter List Depends on chorus type
33 1 00-7F CHORUS PARAMETER 14 Refer to Effect Parameter List Depends on chorus type
34 1 00-7F CHORUS PARAMETER 15 Refer to Effect Parameter List Depends on chorus type
35 1 00-7F CHORUS PARAMETER 16 Refer to Effect Parameter List Depends on chorus type
TOTAL SIZE 6
02 01 40 2 00-7F VARIATION TYPE MSB Refer to Effect MIDI Map 05(=DELAY L,C,R)
00-7F VARIATION TYPE LSB 00 : basic type 00
42 2 00-7F VARIATION PARAMETER 1 MSB Refer to Effect Parameter List Depends on variation type
00-7F VARIATION PARAMETER 1 LSB Refer to Effect Parameter List Depends on Variation type
