■ Analog/digital input and output spec-
ifications
■ Included items
■ Separately sold options
* Appearance and specifications of this product are
subject to change without notice. (04, 2005)
Connectors:
XLR-3-31 type (+48 V phantom power,
switchable), 1/4" TRS phone jack (balanced)
Input impedance:
4 k
Ω (XLR-3-31), 10 kΩ (TRS phone jacks)
Nominal level:
–60 dBu to –22 dBu @ TRIM=max. – min.
PAD OFF
–34 dBu to +4 dBu @ TRIM=max. – min.
PAD ON
Maximum level:
–48 dBu to –10 dBu @ TRIM=max. – min.
PAD OFF
–22 dBu to +16 dBu @ TRIM=max. – min.
PAD ON
Source impedance: 600
Ω
Connectors:
1/4" TRS phone jack (balanced)
Input impedance:
10 k
Ω
Nominal level:
–60 dBu to –22 dBu @ TRIM=max. – min.
PAD OFF
–34 dBu to +4 dBu @ TRIM=max. – min.
PAD ON
Maximum level:
–48 dBu to –10 dBu @ TRIM=max. – min.
PAD OFF
–22 dBu to +16 dBu @ TRIM=max. – min.
PAD ON
Source impedance: 600
Ω
Connector:
1/4" phone jack (unbalanced)
Input impedance:
1 M
Ω
Nominal level:
–60 dBu to –22 dBu @ TRIM=max. – min.
PAD OFF
–34 dBu to +4 dBu @ TRIM=max. – min.
PAD ON
Maximum level:
–48 dBu to –10 dBu @ TRIM=max. – min.
PAD OFF
–22 dBu to +14 dBu @ TRIM=max. – min.
PAD ON
Source impedance: 600
Ω
Connectors:
1/4" phone jack (unbalanced)
Output impedance: 150
Ω
Nominal level:
–10 dBu
Maximum level:
+2 dBu
Load impedance:
10 k
Ω or higher
Connectors:
1/4" phone jack (unbalanced)
Output impedance: 150
Ω
Nominal level:
–10 dBu
Maximum level:
+2 dBu
Load impedance:
10 k
Ω or higher
Connectors:
1/4" phone jack (unbalanced)
Output impedance: 150
Ω
Nominal level:
–10 dBu
Maximum level:
+2 dBu
Load impedance:
10 k
Ω or higher
Connector:
1/4" stereo phone jack
Output impedance: 100
Ω
Maximum level:
50 mW+50 mW @ 32
Ω
Connector:
optical
Format:
24-bit S/P DIF (IEC60958)
Connector:
Type B
Format:
USB2.0 High-Speed device
USB Mass Storage Class
Supported OS:
Window Me, Windows 2000 or later
Mac OS 9.0.4 or later
* If using the D3200 with Windows 98,
please refer to the Korg website or contact
your Korg distributor.
Connectors:
DIN 5-pin
× 2
Connector:
1/4" phone jack (use separately sold PS-1)
Connector:
1/4" stereo phone jack
(use separately sold XVP-10 or EXP-2)
AC cable
Owner’s manual
PS-1 pedal switch
XVP-10 EXP/VOL pedal
EXP-2 foot controller
