Chapter 7
F
rame Memor
y
C:\WINNT\Profiles\Administrator\Desktop\WORK_08_21\370467401
DVS9000WW\01GB09C07-WW.fm masterpage:Left
272
Frame Memory Operations
DVS-9000/9000SF
3-704-674-01 (1)
5
If in step 2 you selected Pattern or [Ext Key] for the mask source, if
required press [Sub Mask1 Invert] to invert the mask source.
6
To link the masks on frame memory source buses 1 and 2, press [Mask
Link], turning it on.
Recalling Images
Recalling an image saved in memory
To recall an image file saved in memory, and allocate it to the frame memory
output, use the following procedure.
1
In the Frame Memory menu, select VF1 ‘Recall’ and HF1 ‘Select.’
2
In the Recall>Select menu, select the target frame memory. (See page
267.)
3
Select HF2 ‘Recall.’
The Recall>Recall menu appears, and the files that can be allocated to this
frame memory appear.
4
Press the button for the desired file.
This recalls the image file, and allocates it to the frame memory selected
in step
2 .
If the pair function is enabled, the files saved as a pair are recalled.
Image Processing
Combining a memory image with an input image
To process the memory image of the frame memory output selected in the
Edit>Select menu (See page 267.), use the following procedure.
1
In the Frame Memory menu, select VF2 ‘Edit’ and HF3 ‘Composite.’
The Edit>Composite menu appears. In this menu, you can also enable the
frame memory pair function (see page 267) or V/K mode (see page 268).
