Switcher Setup
In switcher setup, make settings particular to the switcher processor.
You can make the following settings.
Settings relating to overall switcher configuration (Config)
• System Phase: Adjust the switcher internal reference phase.
• Switch Timing: Specify the timing of video switching.
• M/E Config: Set the program configuration for the M/E and P/P outputs.
• Standard mode: Fix the maximum of four outputs (Out1 to 4) and
program output configuration as follows.
Out1: Program output
Out2: Preview output
Out3: Clean output
Out4: Key preview output
Program output: Clean output + key 1 + key 2 + key 3 + key 4
• Multi-program mode: Increase the number of M/E or P/P programs,
and assign any of the following to the maximum of six outputs (Out1 to
6).
Program outputs 1 to 4, preview output, key preview outputs 1 and 2,
clean output.
Further, you can select the program background from Clean or Utility2,
and change the combination of signals from which it is configured.
Again, you can set the key preview configuration to video mode or key
mode. In key mode, select whether to link operation to the on/off state
of the key, or have it always on.
• DSK mode: Treat P/P as four DSKs, with no background transitions. Of
backgrounds 1 to 4, set one to configure the program output. The signals
which can be selected as the background are limited to Out1 to 6 from
M/E-1.
You can also set the key preview configuration to either video mode or
key mode. In key mode, select whether to link the DSK state to the on/
off operation, or have it always on.
Input signal settings (Input)
• Input Phase Adjust: Carry out phase adjustment for each primary input.
• Through Mode: Set through mode for the input side. This applies only to
the primary inputs, and can be set independently for each primary input.
• Video Process: Switch video processing on or off for each input signal, and
adjust the brightness, hue and so forth.
• Matte Illeg. Color Limit: Switch the illegal limiter on or off for the signal
generated by the switcher internal matte generator.
