SERVICE MANUAL
SPECIFICATIONS
MICROFILM
US Model
Canadian Model
AEP Model
USB HUB UNIT
UH-1000
Mass
500 g (1 lb 1.6 oz)
Dimensions
185
Ч
134
Ч
51 mm (l/w/h) (7
3
/
8
Ч
5
3
/
8
Ч
2
1
/
8
in.)
USB terminals
Upstream : 1, Downstream : 4
Voltage per port
DC + 5V
Current per port
500 mA (max.)
Operating temperature
0 – 40
°
C (32 – 104
°
F)
Supplied accessories
AC power cord (1), USB cable (1), Rubber feet (4), Stand (1),
Instruction manual (1)
NOTICE
This notice is applicable for USA/
Canada only.
If shipped to USA/Canada, install only
a UL LISTED/CSA LABELLED power
supply cord meeting the following
specifications:
SPECIFICATIONS
Plug Type
Nema-Plug 5-15p
Cord
Type SVT or SJT,
minimum 3
×
18 AWG
Length
Maximum 15 feet
Rating
Minimum 7 A, 125 V
