Chapter 6 - Audio setup
Chapter 6
Audio setup
6.1 Introduction
Audio signals from various sources can be recorded onto four audio recording channels. These
channels are identified in the menus as:
•
ch1
•
ch2
•
ch3
•
ch4
The sources used for recording can be:
•
the front microphone,
•
the line or mic. inputs at the rear of the camcorder,
•
AES digital audio signals applied to the BNC input at the right-rear of the camcorder,
•
one of eight embedded SDI audio channels, or
•
an optional wireless microphone receiver.
Audio signals are output:
•
on the rear 5-pin XLR audio output connector,
•
as embedded channels in the SDI output signal, or
•
as AES digital audio signals on the BNC connector on the right-rear of the camcorder.
The following pages will tell you how to:
•
connect the inputs and set input sensitivity,
•
select recording channel sources and set recording levels,
•
monitor channels and sources, and
•
select output channels or sources.
