28 DMC 1000 Digital Media Camcorder User’s Guide (v1.15)
Chapter 2 - Attaching parts
2.7 Mounting a top light
To mount a top light onto the camcorder, proceed as follows:
1. Screw the top light into the screw hole located on the top of the carrying handle or
on top of the viewfinder .
2. Power the top light according to the instructions delivered with the light.
2.7.1 Top light operation
A connector at the top right of the battery plate supplies power for an optional top light.
The top light can be switched on manually with the switch on the light or automatically when
the camcorder is recording. Use the switch
at the bottom of the battery plate to select
between manual and automatic top light operation.
1
2
3
1
2
3
