A-3
Resolution 32-Bit
Number of Channels 1
Max Input frequency TTL-level input 2 MHz
TimeBase Generator
Type Crystal-based Rate Generator (24-Bit)
Number 2 (1 analog input, 1 analog output)
Resolution 125 ns
Output Frequency Range 0.5 Hz to 1 Mhz
Output Levels TTL-compatible
Bus Interface
Type USB
Power
Voltage Range USB or External +5 V
Current Available (*1) +5 V 200 mA maximum
Current Requirements USB powered <500 mA
Physical Characteristics
Size 5.75" D x 7.25" W x 1.60" H
(approximately)
14.61 cm D x 18.42 cm W x 4.06
cm H
Operating Temperature
Range 0 - 50 C
All Specifications are typical at 25 C unless otherwise noted. Note (*1): When powered from an
external source, the on-board power supply circuit can supply up to 200mA at 5VDC to
termination panels through the 50-pin I/O connector.
PARAMETER CONDITIONS SPECIFICATION
TABLE A.1 Hardware Specifications (Continued)
