2

Upgrading and Servicing Guide

removing the pc access panel on the 8000
series

8 Remove the front bezel by following the

appropriate method for your PC model:

To remove the front bezel from the S0000 series
model, gently pry the top section (1) of the
bezel away from the chassis. On the inside of
the front bezel, press the center two tabs (not the
bottom tabs) to release the bezel, and then pull it
from the chassis (2).

removing the front bezel from the S0000
series

To remove the front bezel from the 8000 series,
push up on the two release tabs (1), and then
rotate the front bezel away from the chassis to
release it (2).

removing the front bezel from the 8000
series

removing or upgrading a
drive

Depending on your PC configuration, you may have
up to four of the following storage drives in your PC.

CD-ROM or CD-RW drive

DVD-ROM or DVD+RW/+R drive

Hard disk drive

Diskette drive

7-In-1 memory card reader (select models only)

You need a screwdriver to replace any of the drives.

CAUTION: Back up your personal files on
the hard disk drive to an external storage
device, such as a CD, before removing the
hard disk drive. Failure to do so will result
in data loss. After replacing the hard disk
drive, you need to run System Recovery
using the recovery discs to load the
factory-installed files. See “using
application recovery and system recovery”
for details.
