Page 17

NOTE:

NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO
product offerings and requirements.
NOTE:

NOTE:

NOTE: HP does not allow factory integration of options into standard models listed above.
Configure-to-order servers must start with a CTO Chassis.
NOTE:

NOTE:

NOTE: FIO indicates that this option is available only as a Factory Installable Option.

Step 1: Base Server Blade Configuration

Models

HP ProLiant BL685c G6 CTO Blade (North America)

491338-B21

Two (2) embedded NC532i Dual Port Flex-10 10GbE Multifunction Server Adapters
and one (1) additional 10/100 server adapter dedicated to iLO 2 management

Two (2) small form factor (SFF) SAS/SATA hot plug hard drive bays

Two (2) non-hot plug internal SATA SSD drive bays

HP Embedded SATA Controller

ProLiant Onboard Administrator

Step 2: Choose Required Options (one of the following from each list unless otherwise noted)

Processors

For dual (2) processor configurations choose (one of the following):

AMD Opteron™ processor Model 8435 (2.6 GHz, 6 MB L3 Cache, 75W ACP)
Processor Option Kit, FIO Base

NOTE:

NOTE: If four (4) processors are desired, select one 539816-L21 and one 539816-
B21.

539816-L21

AMD Opteron processor Model 8431 (2.4 GHz, 6 MB L3 Cache, 75W ACP)
Processor Option Kit, FIO Base

NOTE:

NOTE: If four (4) processors are desired, select one 539819-L21 and one 491341-
B21.

539819-L21

AMD Opteron processor Model 8389 (2.9 GHz, 6 MB L3 Cache, 75W ACP)
Processor Option Kit, FIO Base

NOTE:

NOTE: If four (4) processors are desired, select one 491341-L21 and one 491341-
B21.

491341-L21

AMD Opteron processor Model 8387 (2.8 GHz, 6 MB L3 Cache, 75W ACP)
Processor Option Kit, FIO Base

NOTE:

NOTE: If four (4) processors are desired, select one 491343-L21 and one 491343-
B21.

491343-L21

Low Power AMD Opteron processor Model 8381 HE (2.5 GHz, 6 MB L3 Cache,
55W ACP) Processor Option Kit, FIO Base

NOTE:

NOTE: If four (4) processors are desired, select one 508864-L21 and one 508864-
B21.

508864-L21

Memory

2 GB REG PC2-6400 DDR2 2 x 1 GB Kit

497763-B21

4 GB REG PC2-6400 DDR2 2 x 2 GB Kit

497765-B21

8 GB REG PC2-6400 DDR2 2 x 4 GB Kit

497767-B21

8 GB REG PC2-6400 DDR2 2 x 4 GB Low Power Kit

504351-B21

16 GB REG PC2-5300 DDR2 2 x 8 GB Dual Rank Kit

408855-B21

64 GB REG PC2-5300 DDR2 8 x 8 GB Dual Rank Kit

495605-B21

NOTE:

NOTE: Must be installed in pairs.

QuickSpecs

HP ProLiant BL685c Generation 6 (G6) Server Blade

Configuration Information - Factory Integrated Models

DA - 13243 Worldwide — Version 2 — June 2, 2009

Page 17
