HP Proliant DL580 - Manual (Page 6)

Expansion Slots Expansion Slots Expansion Slots Expansion Slots
Expansion Expansion Expansion Expansion
Slots with Slots with Slots with Slots with
PCI Express x8 PCI Express x8 PCI Express x8 PCI Express x8
Card Card Card Card
Expansion Slot Expansion Slot Expansion Slot Expansion Slot
# # # #
Technology Technology Technology Technology Width Width Width Width Connector Connector Connector Connector
Width Width Width Width *
Bus Number Bus Number Bus Number Bus Number ** Form Factor Form Factor Form Factor Form Factor Notes Notes Notes Notes
1 PCI Express x8 x16 42h FH/FL
2 PCI Express x8 x16 42h FH/FL
3 PCI Express x8 x16 42h FH/FL
4 PCI Express x8 x16 12h FH/FL
5 PCI Express x8 x16 12h FH/FL
6 PCI Express x8 x16 12h FH/FL
7 PCI Express x8 x16 24h FH/FL
8 PCI Express x4 x8 24h FH/FL
9 PCI Express x4 x8 24h LP
10 PCI Express x4 x8 24h LP
11 PCI Express x4 x8 24h LP
* Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment number.
** Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest Device ID by bus (starting with the
lowest bus).
FL= Full length; FH = Full height; LP = low-profile.
Manageability Manageability Manageability Manageability Integrated Lights-Out (iLO 2) Management 2 (integrated on motherboard)
Virtual Text Remote Console (pre-OS only)
Remote Serial Console
Virtual Power Button Control
Virtual Unit ID control
Integrated Remote Console (ActiveX Control client)
Dedicated & full function shared network connectivity with VLAN
Embedded system health
Browser, command line and scripted access
Automatic IP Configuration via DHCP/DNS/WINS
Industry Standard 128-bit Secure Sockets Layer (SSL) and Secure Shell security (SSH)
Advanced Encryption Standard (AES)/Triple Data Encryption Standard (3DES)
OS independent hardware health status
IML and iLO Event Logging
Support for 12 user accounts with customizable access privilege
Storage Controller Storage Controller Storage Controller Storage Controller
One of the following
depending on Model
2P Base Models HP Smart Array P400i/256 MB Controller
4P High Performance
Models HP Smart Array P400i/512 MB BBWC Controller
QuickSpecs
HP ProLiant DL580 Generation 5 (G5) HP ProLiant DL580 Generation 5 (G5) HP ProLiant DL580 Generation 5 (G5) HP ProLiant DL580 Generation 5 (G5)
Standard Features
DA - 12770 Worldwide — Version 18 — July 18, 2008 Page 6
