HP Proliant DL580 - Manual (Page 43)

1 Slimline media bay
2 Half-height bay
3 Second SAS drive bay (supports up to 8 additional SFF
SAS/SATA drives)
4 8 SFF hot-plug SAS/SATA drives
Drive Support Drive Support Drive Support Drive Support
Quantity Quantity Quantity Quantity
Supported Supported Supported Supported
Position Position Position Position
Supported Supported Supported Supported Controller Controller Controller Controller
Slimline Drives Slimline Drives Slimline Drives Slimline Drives
IDE slimline CD-ROM
Drive 1 1 Integrated IDE
Slimline DVD-ROM Drive
(8X/24X) Option Kit 1 1 Integrated IDE
Hard Drives Hard Drives Hard Drives Hard Drives
SAS SFF Hot Pluggable Drives SAS SFF Hot Pluggable Drives SAS SFF Hot Pluggable Drives SAS SFF Hot Pluggable Drives
Quantity Quantity Quantity Quantity
Supported Supported Supported Supported
Position Position Position Position
Supported Supported Supported Supported Controller Controller Controller Controller
146GB 3G SAS 10K SP
146GB 3G SAS 10K DP
72GB 3G SAS 10K SP
72GB 3G SAS 10K DP
72GB 3G SAS 15K SP
72GB 3G SAS 15K DP
36GB 3G SAS 15K SP
36GB 3G SAS 15K DP Up to 8 4 HP Smart Array E200/128 BBWC Controller
HP Smart Array E500/256 MB Controller
HP Smart Array P400i/256 MB Controller
HP Smart Array P400i/512 MB BBWC Controller
HP Smart Array P600/256 BBWC Controller
HP Smart Array P800/512 BBWC Controller
SFF SATA Hot Plug Entry (ETY) Drives SFF SATA Hot Plug Entry (ETY) Drives SFF SATA Hot Plug Entry (ETY) Drives SFF SATA Hot Plug Entry (ETY) Drives
Quantity Quantity Quantity Quantity
Supported Supported Supported Supported
Position Position Position Position
Supported Supported Supported Supported Controller Controller Controller Controller
120GB 1.5G SATA 5.4K Up to 8 4 HP Smart Array E200/128 BBWC Controller
HP Smart Array E500/256 MB Controller
HP Smart Array P400i/256 MB Controller
HP Smart Array P400i/512 MB BBWC Controller
HP Smart Array P600/256 BBWC Controller
HP Smart Array P800/512 BBWC Controller
