HP Proliant DL580 - Manual (Page 50)

CD-ROM Mode-1 650 MB (550
MB)
Mode-2 742 MB (640
MB)
Block Size Block Size Block Size Block Size DVD 2,048 bytes
CD 2,352 (Mode-
0)
2352, 2340,
2336, 2048
bytes
(Mode-1)
2352, 2340,
2336, 2048
bytes
(Mode-2)
Diameter Diameter Diameter Diameter 120 mm (4.7 in), 80 mm (3.1 in)(with adapter at
vertical mounting mode)
Loading Mechanism Loading Mechanism Loading Mechanism Loading Mechanism Tray type
Interface Interface Interface Interface EIDE (ATAPI)
Access Times Access Times Access Times Access Times (typical) Random DVD-ROM < 120 ms, CD-ROM < 110 ms
Full-Stroke DVD-ROM < 240 ms, CD-ROM < 160 ms
Audio Output Level Audio Output Level Audio Output Level Audio Output Level
(typical) Line-out CD 0.7 Vrms at 47 Kohms Load
Data Transfer Rate Data Transfer Rate Data Transfer Rate Data Transfer Rate
(sustained) DVD-ROM Single Layer 10.8 MB/sec. Max.
DVD-RAM 2.77 MB/sec. Max
CD-ROM 7.2 MB/sec. Max.
Cache Buffer Cache Buffer Cache Buffer Cache Buffer 2 MB
Spin-up Time Spin-up Time Spin-up Time Spin-up Time (typical) less than 10 seconds
MTBF MTBF MTBF MTBF 120,000 Power On Hours
(POH)
Ambient Temperature Ambient Temperature Ambient Temperature Ambient Temperature Operating -22° to 140° F (-30° to 60° C)
Relative Humidity Relative Humidity Relative Humidity Relative Humidity Operating 10% to 80%
Storage/Transportation 5% to 95%
Dimensions Dimensions Dimensions Dimensions (HxWxD, maximum) 0.5 x 5.04 x 5.1 in (12.7 x 128 x 129.4 mm)
Option Kit Contents Option Kit Contents Option Kit Contents Option Kit Contents DVD-ROM drive with installation guide, warranty card, registration card
QuickSpecs
HP ProLiant DL580 Generation 5 (G5) HP ProLiant DL580 Generation 5 (G5) HP ProLiant DL580 Generation 5 (G5) HP ProLiant DL580 Generation 5 (G5)
Technical Specifications
DA - 12770 Worldwide — Version 18 — July 18, 2008 Page 50
