2. Attach power nozzle
a. Attach power nozzle at the
end of the extension wand. Be
sure the nozzle is locked in place.
To release, press down on the
center of the plastic spring latch
and remove nozzle.
b. Position cord into cord clips
on extension wands, placing ex-
cess cord between nozzle and
bottom cord clip.
c. To attach the hose and
extension wands, rotate the
plastic latch ring on hose grip to
accept the button projection on
the extension wands.
Push the handle over the wand
so that the button projection fits
into the slot. Turn the outer ring
on the handle to lock the handle
and wand in place.
d. Connect nozzle power cord to
receptacle underneath handle.
6
