17
Figure 3. Diagram of the LCOR-HVB-IPI and RCOR-HVB-IPI
12
(305mm)
Ø 8
(204mm)
34-3/4
(882mm)
4-3/4
(121mm)
37-7/16
(950mm)
ELECTRICAL
ACCESS
GAS LINE
ACCESS
42-5/8
(1082mm
2-5/16
(58mm)
21
(533mm)
24-1/8
(612mm)
8-1/2
(216mm)
21
(533mm)
42
(1066mm
32-5/16
(820m)
17-15/16
(455mm)
2-9/16
(64mm)
1/2
(13mm)
(4)
5-1/4
(133mm)
12
(305mm)
29-1/4
(743mm) 7-1/4
(184mm)
Ø 8
(204mm)
10
(254mm)
REAR VENT
COLLARS
ELECTRICAL
ACCESS
GAS LINE
ACCESS
GAS CONTROLS
& LABELS
END GLASS
DOOR
TOP STANDOFFS TOP VENT
COLLARS
SIDE GLASS
DOOR
