U Remote control signal sensor . . . . . . . . . . . . . . . . . . . . . . . . . 6
V Disc tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
W L2 input terminals (L2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 X Display
Y Time slip indicator (TIME SLIP) . . . . . . . . . . . . . . . . . . . . . . . 22
A Timer recording display
On: When timer recording is on standby ( ➜page 24)
Flashes: When the unit couldn’t go to timer recording standby
B Disc type
C The display mode of the main display section
GRP: Group number
TITLE: Title number
PL: Play list number
CHAP: Chapter number
PG: Program number
TRACK: Track number
D Recording mode ( ➜page 15)
E DVD indicator
Flashes: When you press [ Í, DVD POWER] to turn the unit off
until it actually turns off
F Channel
G Main display section
Recording and play counter, and other miscellaneous messages
Main unit
(L2)
POWER/STANDBY
S VIDEO IN VIDEO IN
LINE 2
L (mono) AUDIO IN R
/
OPEN/CLOSE
REC MODE
TIME SLIP FF/SKIP SKIP/FR PLAY STOP
CHANNEL REC ERASE
1 U V G ? H F B
J 6 K 7 O Y X W
Controls such as 1 function the same as the buttons on the remote control.
The unit’s display
) * + - ,
. /
Center circle (e.g., DVD-RAM)
Rotating (REC):recording
Stopped (REC):recording paused
Rotating (REC, PLAY):
Chasing play or simultaneous
rec and play is in progress
Rotating (PLAY):playing
Stopped (PLAY):play paused
“PLAY” flashes:
the resume function ( ➜page 16,
To stop play) is working
