Bi-fold Glass Doors
B. Fireplace Components
GR38
Integral Grate
Traditional Brick Pattern Refractory
Herringbone Pattern Refractory
20 in.
(508 mm)
66 in.
(1676 mm)
1/2 in.
(13 mm)
HX4 Hearth Extension
Outside Air
Shield 2 Wire Ties
Flexible Duct
(not supplied)
Inlet Ring
AK22 Outside Air Kit
18 in.
(457 mm)
SLA10 Adaptor
Catalog # Description
EXCLAIM-42H-C Fireplace with Integral Grate, Outside air Kit, Hearth Protection Strips and Herringbone Pattern Refractory
EXCLAIM-42T-C Fireplace with Integral Grate, Outside air Kit, Hearth Protection Strips and Traditional Brick Pattern Refractory
DM8042 Glass Doors - Bi-fold, Clear-View - Black
DM8042B Glass Doors - Bi-fold, Clear-View - Polished Bradd
DM8042S Glass Doors - Bi-fold, Clear-View - Stainless Steel
HX4 Hearth Extension
GR38 Integral Grate (included with ¿ replace)
AK22 Outside Air Kit (included with ¿ replace)
