Heat & Glo • EXCLAIM-42C • 4013-094 Rev I • 10/06 16
• Remove ¿ replace from pallet. The ¿ replace is attached
to pallet with two brackets on each side and rear of outer
shell. See Figure 4.11. Remove screws from bracket, pallet
and
¿ replace. Replace screws removed from ¿ replace.
Slide ¿ replace into position (brackets can be used to
anchor ¿ replace in position). Once ¿ replace has been put
into position, install refractories.
Figure 4.11 Removing Shipping Brackets
Note: If DM8042 Series Doors are to be installed onto this
¿ replace at any time, we recommend they be installed at
the same time as refractory to avoid the need to remove
refractory at a later date.
• Install back refractory, making sure refractory is
centered and notches are to the bottom of ¿ rebox. Place
grate brackets in outer two notches of refractory. See
Figure 4.13.
• Secure back refractory in place with a screw and bracket
supplied in hardware package. See Figure 4.14.
Note: Before installing refractories and hearth stone, be
sure all back edges of each piece are smooth to ensure
proper
¿ t. Scrape away excess with a regular screwdriver.
See Figure 14.12.
Figure 4.12 Scrape Away Rough Edges
REFRACTORY
BRACKET
Figure 4.14 Attaching Back Refractory
GRATE BRACKETS
Figure 4.13 Back Refractory with Grate Brackets in Place
