Model 291
3-16 307
Figure &
Item No. Part No. Description Qty.
3-9 DRAIN PAN AND FILTER ASSEMBLY
1 52194 CRUMB CATCHER (OPTIONAL) ............................ 1
2 03204 CRUMB CATCHER BASKET W/HANDLE (OPTIONAL) 1
2 21010 CRUMB CATCHER BASKET ASSEMBLY .............. 1
2 24429 HANDLE - CRUMB BASKET ................................... 1
3 52496 FILTER DRAIN PAN ASSEMBLY ............................ 1
4 52487 CASTER ....................................................................... 2
5 SC01-009 SCREW 1/4-20 X 1/2 .................................................... 8
6 NS02-002 NUT 1/4-20 ................................................................... 8
7 17505 FILTER CLIPS ............................................................. 2
8 17503(use 14674) BOTTOM FILTER SCREEN (SN:BE0503009 AND BELOW) .. 1
8 65447 BOTTOM FILTER SCREEN (SN: BE0503010 AND ABOVE) .. 1
9 17502(use 14674) TOP FILTER SCREEN (SN:BE0503009 AND BELOW) ........... 1
10 36305 WASHER & STANDPIPE ...................................................... 1
11 24212 STANDPIPE ASSEMBLY (SN:BE0503009 AND BELOW) ...... 1
11 14658 KIT, 8 HEAD PICK-UP TUBE (SN: BE0503010 AND ABOVE)
√√√√√
12 17431 (use 69289) UNION - MALE FITTING .......................................... 1
√√√√√
13 17432 (use 69289) UNION - HANDLE FITTING .................................... 1
14 24211 WELDMENT, FILTER TUBE AND WASHER ......... 1
15 23740 HANDLE, STANDPIPE 8 HEAD .............................. 1
16 SC01-245 SCREW 10-32 X 1/2 ..................................................... 3
17 23804 INSERT, FILTER NUT ................................................ 1
18 OR01-007 O-RING, FILTER NUT INSERT ................................. 1
19 23803 FILTER NUT (SN:BE0503009 AND BELOW) .......... 1
19 66535 FILTER NUT (SN: BE0503010 AND ABOVE) ......... 1
20 62082 FILTER DRAIN PAN COVER ASSEMBLY ............. 1
√√√√√
21 12102 FILTER ENVELOPE PAPER (100 PER CARTON) . 1
22 65776 ROD - LONG CLEAN OUT ....................................... 1
√√√√√
23 35771 BRUSH ......................................................................... 1
24 35310 STIRRER ...................................................................... 1
√√√√√
25 12126 BLACK L-BRUSH ...................................................... 1
26 65211 CRUMB CATCHER .................................................... 1
√ √ √ √ √ recommended parts
* not shown
