SKU 65761

For technical questions, please call 1-800-444-3353.

Page 9

packing the bearings.

Using a suitable solvent, clean the

3.

bearings and the rest of the parts in

the Hub assembly. The parts must be

cleaned even if they are new or ap-

pear clean.
Allow all pieces to dry completely.

4.

Place fresh, clean bearing grease in

5.

the packer.
With the grease-filled bearing packer

6.

in one hand and the bearing in the

other, press the bear ing into the

grease, forcing the grease inside the

slots in the bearing, continue doing

this until every slot in the bearing is

completely full of grease.

Hub and Wheel assembly

Put a Seal (59) and Bearing (49) on

7.

the Axle and then put the Tire (48) on

the Axle.
With each Tire in place, add a Wash-

8.

er (50) and a Spindle Nut (51) onto

the ends of the Axles. Tighten the

Spindle Nuts to 20-25 ft. pounds and

turn each tire several times to seat

the bearing. Back off the Spindle Nut

one half turn. Insert a Cotter Pin (25)

through both the Axle and the Spindle

Nut (51) and bend the end of the Pin

back to hold it in place. Last, tap on a

Wheel Cap (61).

connecting the rail assembly to the oil

tank

Insert the Front Leg Assembly (11)

9.

into the bracket on the Oil Tank As-

sembly (10B). Insert the remaining

Hex Head Bolt (16) through the hole

in the middle of the bracket of the Oil

Tank Assembly. Secure it with a Hex

Head Nut (17) and a Hex Head Bolt

(16).

note: When travelling, remove the Push

Pin (26) and Hair Pin Clip (29) and lift

the Front Leg Assembly up so that it

is parallel to the Rail Assembly. Re-

place the Push Pin (26) and Hair Pin

Clip (29) into the Horizontal Transport

Hole shown just above the Oil Plug.
To connect the Rail Assembly (2) to

10.

the Oil Tank Assembly, insert a Hex

Head Bolt (16) into the middle hole

of the “L” shaped bracket on the Oil

Tank Assembly. Secure it with a Hex

Head Nut (17).
In FIGURES 1 and 2 (see next page),

11.

the Rail Assembly (2) is shown in

Horizontal mode for opera tion and

travel (as mentioned above, the Front

Leg Assembly (11) must be secured

up in the horizontal position when

travelling).
