NVIDIA Quadro NVS NVIDIA Quadro NVS NVIDIA Quadro NVS NVIDIA Quadro NVS
285
285 285 285 (128MB DH) PCIe PCIe PCIe PCIe
x16 Dual-display x16 Dual-display x16 Dual-display x16 Dual-display
Graphics Card
Graphics Card Graphics Card Graphics Card
Form Factor Form Factor Form Factor Form Factor Low profile, both ATX and low profile brackets included
Graphic Controller Graphic Controller Graphic Controller Graphic Controller Integrated Quadro 285 2D graphics processor unit (GPU)
Bus type Bus type Bus type Bus type PCI-Express
Memory Memory Memory Memory 128 MB DDR (64 MB local frame buffer plus 64 MB of system memory via
TurboCache)
Connector Connector Connector Connector DMS-59 to dual-DVI Y-cable or dual-VGA Y-cable
Dimensions Dimensions Dimensions Dimensions Low-profile, 2.586 x 6.6 in (6.57 x 16.76 cm)
Multi-monitor support Multi-monitor support Multi-monitor support Multi-monitor support Dual analog or digital monitors
RAMDAC RAMDAC RAMDAC RAMDAC Dual 350 MHz (integrated)
Maximum Pixel Clock Maximum Pixel Clock Maximum Pixel Clock Maximum Pixel Clock 350 MHz
Overlay Planes Overlay Planes Overlay Planes Overlay Planes One 16-bit Video overlay plane
High-definition Video High-definition Video High-definition Video High-definition Video
Processor
Processor Processor Processor (HDVP)
Full screen, full frame video playback of HDTV and DVD content
DVD-ready motion compensation for MPEG-2
Independent hardware colour controls for video overlay
Hardware colour-space conversion (YUV 4:2:2 and 4:2:0)
IDCT motion compensation
5-tap horizontal by 3-tap vertical filtering
8:1 up/down scaling
Resolution Resolution Resolution Resolution Analog Resolution* Analog Resolution* Analog Resolution* Analog Resolution* Maximum Colors Supported Maximum Colors Supported Maximum Colors Supported Maximum Colors Supported Maximum Refresh Rate Maximum Refresh Rate Maximum Refresh Rate Maximum Refresh Rate
800 x 600
1024 x 768
1280 x 1024
1600 x 1200
16.7 M
16.7 M
16.7 M
16.7 M 240 Hz
240 Hz
150 Hz
100 Hz
Digital Resolution* Digital Resolution* Digital Resolution* Digital Resolution* Maximum Colors Supported Maximum Colors Supported Maximum Colors Supported Maximum Colors Supported Maximum Refresh Rate Maximum Refresh Rate Maximum Refresh Rate Maximum Refresh Rate
800 x 600
1024 x 768
1280 x 1024
1600 x 1200
16.7 M
16.7 M
16.7 M
16.7 M 75 Hz
75 Hz
60 Hz
60 Hz
NOTE: NOTE: NOTE: NOTE: * Supported resolution is determined by the combination of HP Blade
Workstation graphics driver, HP Blade Workstation Client administration
software and client graphics driver. When used with multiple displays,
orientation can be set in combinations of 1x2, 2x1, 1x3, 3x1, 1x4, 4x1, or
2x2 placement, each in landscape or portrait mode.
QuickSpecs
HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client
Technical Specifications - Graphics adapter
DA - 12705 Canada — Version 1 — February 12, 2007 Page 14
