Integrated Intel 82566DM Integrated Intel 82566DM Integrated Intel 82566DM Integrated Intel 82566DM
Gigabit Network
Gigabit Network Gigabit Network Gigabit Network
Connection
Connection Connection Connection
Connector Connector Connector Connector RJ-45
Controller Controller Controller Controller Intel Nineveh Gigabit platform LAN Connect Networking Controller
Memory Memory Memory Memory Integrated 96KbB on chip buffer memory
Data rates supported Data rates supported Data rates supported Data rates supported 10/100/1000 Mbps
Compliance Compliance Compliance Compliance IEEE 802.1P, 802.1Q, 802.2, 802.3, 802.3 ab and 802.3u compliant,
Bus architecture Bus architecture Bus architecture Bus architecture GLCI, LCI interface. Intel specific MAC to PHY interface
Data transfer mode Data transfer mode Data transfer mode Data transfer mode At gigabit GLCI (802.3 serdes) is for Data, LCI (parallel bus)for MDIO, at
10/100 LCI for both data and MDIO, GLCI is idle.
Hardware certifications Hardware certifications Hardware certifications Hardware certifications FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark
for European Union
Power requirement Power requirement Power requirement Power requirement Require 3.3Vaux,1.8V and 1.0V or just 3.3V with integrated regulators
Power consumption 1.16 Watts for 82566, whole LOM 2.53 Watts
ACBS ACBS ACBS ACBS Intel Auto Connect Battery Saving feature
Boot ROM support Boot ROM support Boot ROM support Boot ROM support Yes
Network transfer mode Network transfer mode Network transfer mode Network transfer mode Full-duplex
Half-duplex (not available for the 1000BASE-T transceiver)
Network transfer rate Network transfer rate Network transfer rate Network transfer rate 10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps
Environmental Environmental Environmental Environmental Operating temperature Operating temperature Operating temperature Operating temperature 32° to 131°F (0° to 55° C)
To 70° C for external regulator
Operating humidity Operating humidity Operating humidity Operating humidity 85% at 131° F (55° C)
Management capabilities Management capabilities Management capabilities Management capabilities WOL, auto MDI crossover, PXE, Muti-port teaming, RSS, Advanced cable
diagnostic.
Alerting Alerting Alerting Alerting ASF 2.0 support
QuickSpecs
HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client
Technical Specifications - Communications
