A complete Parts List is available at www.HobartWelders.com
OM-925 Page 17
5-6. Selecting A Location And Connecting Input Power
1 Rating Label
2 Grounded Receptacle
A 115 volt, 20 ampere individual branch
circuit protected by time-delay fuses or
circuit breaker is required.
3 Plug From Unit
Select extension cord of 12 AWG for up to
50 ft (15 m) or 10 AWG for 50 up to 100 ft
(30 m).
! Special installation may be
required where gasoline or volatile
liquids are present − see NEC
Article 511 or CEC Section 20.
3
803 712-C
! Do not move or operate unit
where it could tip.
2
1
18 in
(460 mm)
18 in
(460 mm)
