With running deck in lowered
position, place CONSOLE
on upright masts. Slide the
brackets that are underneath
the console into the top holes of
the upright masts.
Place LOCK WASHER (E) and LOCK WASHER (E) LOCK WASHER (E)
BOLT (D) into flat side of BOLT (D) BOLT (D) LEFT
upright MAST upright upright and tighten. MAST MAST
Place ARC WASHER (F) and ARC WASHER (F) ARC WASHER (F)
BOLT (D) into curved side of BOLT (D) BOLT (D)
LEFT upright LEFT LEFT MAST upright upright and tighten. MAST MAST
Gently lift RIGHT side of the RIGHT RIGHT
console to connect the CONSOLE
CABLE. Carefully tuck wires in CABLE CABLE
mast to avoid damage. NOTE:
Do not pinch console cable or
grip pulse wires.
Repeat steps 2-3 above to
assemble the right side upright
mast and console.
INTRODUCTION
IMPORT
ANT
PRECAUTIONS
ASSEMBL
Y
BEFORE YOU
BEGIN
TREADMILL OPERA
TION
CONDITIONING GUIDELINES
TROUBLESHOOTING &
MAINTENANCE
LIMITED WARRANTY
8
ASSEMBLY STEP 3
ASSEMBLY STEP 4
A
B
C
A
B
* Be sure to tighten bolts after all are lined up.
BOLT (D)
LOCK WASHER (E)
ARC WASHER (F)
ARC WASHER (F)
CONSOLE CABLE
DO NOT ATTACH
THIS SIDE UNTIL STEP 4
ASSEMBLED IN STEP 3
