F. Water Circuit Assembly
AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS
M-0, N-1, N-, P-0, P-1, Q-0, R-0, R-1, R-
Title: F. Water Circuit Assembly Model: AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS
Index
No. Description
Material or Model
Number
Part Number
Required Number
M-0
to
N-
P-0
to
R-
1 Water Valve V19 0.8m/min 458548-01 1 1
1a Cross – Recessed Hex Bolt
SW 4×10, SS 7B030410 -
Hex Bolt Assy (LF) 4×1, SS 7B03041
Tube – Water Valve SI.R 4X7938-01 1 1
3 Clamp SK-15 435934-03 1 -
Hose Clamp 3 HC 593 4A017-07 1
4 Fitting (C) - 4A340-01 1
5 Water Valve Bracket SS 4A3475-01 1
6 Rubber Gasket - 413854-03 1
1a
1
3
4
5
6
