13
Title: C. Ice Making Mechanism Assembly Model: AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS
Index
No. Description
Material or Model
Number
Part Number
Required Number
M-0
to
P-1
Q-0
to
R-
1 Bracket (R) ABS 1H637-01 1 1
Bracket (L) ABS 1H636G01 1 -
1H636-01 1
3 Guide – Rear ABS 3X386-01 1 1
4 Guide – Front ABS 3X3861-01 1 1
5 Separator ABS 4X7933-01 6 6
6 Frame – Pipe ABS 4X8068-01
7 Ice Chute ABS 3X3863-01 1 1
8 Nozzle (A) ABS H4536-01 1 1
9 Cap SI.R 4X7936-01
10 Suction Tube SI.R 4X7937-01 1 1
11 Discharge Tube SI.R 3X3864-01 1 1
1 Water Tank ABS H4535-01 1 1
13 Pump Motor LMP-0CPA-U6 463045-01 1 1
13a Cross-Recessed Hex Bolt
SW 4×10, SS 7B030410 3 3
14 Holder – Thermistor PE 3H964-01 1 1
14a T Screw 4×8, SS 7P3-0408 1 1
15 Joint POM 4X7934-01 1 1
16 Reducing Pipe ABS 4A903-01 1 1
17 T Screw 4×10, SS 7P3-0410
18 T Screw 4×10, SS 7P3-0410
19 Gasket (B1) - 4A3355-01
0 Gasket (B) - 4A3355-0
