10
Title: B. Refrigeration Assembly Model: AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS
Index
No. Description
Material or Model
Number
Part Number
Required Number
M-0
to
R-
1 Compressor QA51K13GAU6 45594-01 1
1a Rubber Grommet - 438844-01 4
1b Bolt - 448834-01 4
PTC Relay MM8-5CDP4M7 4565-01 1
3 Motor Protector MM3-38ECA 45654-01 1
4 Protector Cover 45655-01 1
5 Clamp 438846-01 1
6 Clip 438847-01 1
7 Copper Tube (H) AM-50BAE
AM-50BAE-DS 3X6440G01 1
AM-50BAE-AD
AM-50BAE-ADDS 3X6440G0 1
8 Copper Tube (J) 4A958-01 1
9 Condenser – Air Cooled H5586-01 1
9a T Screw 4×8 7P31-0408
10 Plate – Cond AM-50BAE
AM-50BAE-DS 4Y0199-01 1
AM-50BAE-AD
AM-50BAE-ADDS
GS 4Y0199-0 1
10a T Screw 4×8 7P31-0408
11 Guide – Cond GS 4Y000-01 1
11a T Screw 4×8 7P31-0408
1 Fan Motor SPBB4ER1 440916-01 1
1a Screw - 436863-01 3
13 Fan Blade - 455943-01 1
13a Washer - 435983-01 1
13b Hex Nut - 4A1345-01 1
14 Guide – Drain GS 4Y0191-01
14a T Screw 4×8 7P31-0408
15 Grommet Top EPDM 3A508-01 1
16 Grommet Bottom EPDM 3A508-0 1
17 Bracket – Fan Motor GS 4X649-01 1
17a Hex. Bolt SW 5×10 7B030510
18 Valve Body 4 440351-01 1
19 Coil – Valve ADS-4HD 440354-01 1
0 Bolt - 440354F01 1
1 Base GS H5574G01 1
Evaporator - 3X3948G01 1
3 Heat Exchanger AM-50BAE
AM-50BAE-DS 3X6438G01 1
AM-50BAE-AD
AM-50BAE-ADDS 3X6438G0 1
4 Drier DY-1QHD-03 445655-04 1
