Microtower and Small Form Factor
Maximum Memory*
Supports up to 8-GB of DDR2 SYNCH DRAM. Slot 1 is black and must always be populated. Not
all memory configurations possible are represented below.
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system, all
memory may not be available due to system resource requirements. Addressing memory above 4
GB requires a 64-bit operating system.
DIMM Size
Slot
Channel A
Channel B
1 (black)
2 (white)
3 (black)
4 (white)
512-MB
512-MB
1-GB
1-GB
1-GB
(dual-channel symmetric)
512-MB
512-MB
2-GB
(dual-channel symmetric)
1-GB
1-GB
2-GB
(dual-channel symmetric)
512-MB
512-MB
512-MB
512-MB
3-GB
(dual-channel symmetric)
1-GB
512-MB
1-GB
512-MB
4-GB maximum
(dual-channel symmetric)
1-GB
1-GB
1-GB
1-GB
8-GB maximum
(dual-channel symmetric)
2-GB
2-GB
2-GB
2-GB
* The Intel Q33 Express chipset includes a built-in Management Engine (ME), which allocates memory for manageability
functions. Management Engine memory is shared with system memory. If the PC contains a single DIMM, 16 MB of memory
is pre-allocated for it at system startup. If the PC contains two DIMMs, 32 MB of memory is pre-allocated. This memory is
not made available to the operating system, just as pre-allocated video memory is not available.
MT
SFF
Memory Configurations
One of the following
512-MB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (1 x 512)
X
X
1-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (1 x 1GB)
X
X
1-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (2 x 512)
X
X
2-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (1 x 2GB)
X
X
2-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (2 x 1GB)
X
X
2-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (4 x 512)
X
X
3-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (3 x 1GB)
X
X
4-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (4 x 1GB)
X
X
4-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (2 x 2GB)
X
X
8-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (4 x 2GB)
X
X
