DVI ADD2 Graphics
1
Models
HP ADD2 SDVO DVI-D Out Adapter
Form Factor
Low-profile card
DVI-D Connector
Digital connection only
Dual Head Support
Yes, when used with the integrated VGA connector
Display Devices
Supported
HP L1740
HP L1940T
HP L2045W
HP LP1965
NOTE: These graphics adapters offer optimal performance with any display that meets applicable
VESA standards.
Color Depth
All modes support 8-bpp, 16-bpp, and 24-bpp color depths
Host Interface
Connector
Mechanically compliant with PCI-E standard
Complies with the Intel ADD2 and Intel Serial Digital Video Output
(SDVO) specifications
Dot Clock
165 MHz maximum
Display Modes
Supports display modes that require up to 165-MHz bandwidth on the
link, as shown in the following table.
Resolution
60-Hz LCD
60-Hz
75-Hz
85-Hz
Blanking
5% reduced
GTF
GTF
GTF
640 x 480
VGA
Yes
Yes
Yes
Yes
800 x 600
SVGA
Yes
Yes
Yes
Yes
1024 x 768
XGA
Yes
Yes
Yes
Yes
1280 x 1024
SXGA
Yes
Yes
No
No
1600 x 1200
UXGA
Yes
Yes
No
No
NVIDIA Quadro NVS
290 256MB PCIe Dual
Head
Form Factor
Low Profile
Bus Type
PCIe x16
Memory
256 MB 400MHz DDR2 SDRAM unified frame buffer, Z-buffer and
Texture storage
Connector
DMS-59, includes DMS-59 to Dual DVI-I cable. DMS-59 to Dual VGA
cable available as an option.
Display Resolution
Support
Dual integrated analog display controllers supporting up to two analog
displays at 2048x1536 @ 85Hz on both displays or dual digital displays
at 1920x1200 (single-link).
NVIEW advanced multi-display desktop and application management
seamlessly integrated into Microsoft Windows
RAMDAC
Integrated dual 400MHz
Color planes
32-bit color buffer
Overlay planes
Hardware supported
nView architecture
Advanced multi-display desktop & application management seamlessly
integrated into Microsoft Windows.
Multi-Monitor support
Dual monitor support
DVI support
DMS-59 (to dual DVI-SL)
High-definition Video
Processor (HDVP)
Full-screen, full-frame video playback of HDTV and DVD content
DVD-ready motion compensation for MPEG-
2Independent hardware color controls for video overlay
QuickSpecs
HP Compaq dc5800 Business PC
Technical Specifications - Graphics
DA - 12863 U.S. QuickSpecs — Version 3 — 4/2/2008
