Smart Array P410i
Controller Dimensions Embedded
Disk Drive and
Enclosure Interface -
Transfer rate 6Gb/s SAS (Serial Attached SCSI)
3Gb/s SATA (Serial ATA)
SAS Connectors 2 internal 4X connectors
Cache Memory Speed DDR2-800MHz with 40 or 72-bit wide bus
Server Interface x4 PCIe 2.0 provides 2GB/s maximum bandwidth
SAS Speed 8 6Gb/s SAS links provide 4.8GB/s maximum bandwidth
Cache Memory Zero Memory RAID has no cache memory
40-bit 256MB ECC protected cache (battery upgrade available)
72-bit 512MB BBWC or 72-bit 512MB and 1G FBWC
Logical Drives
Supported Zero Memory, Up to 2 logical volumes (8 physical drives)
Up to 64 logical drives with cache
Host Memory
Addressing 64-bit, supporting greater than 4GB server memory space
RAID Support RAID 6, 6+0 (Advanced Data Guarding)
NOTE: RAID 6, 6+0 can be enabled with one of the following
combinations:
256 MB cache, Battery kit and Smart Array Advanced Pack
License key option upgrades
512 MB BBWC/FBWC and Smart Array Advanced Pack License
key option upgrades
1G FBWC and Smart Array Advanced Pack License key option
upgrades
RAID 5, 5+0 (Distributed Data Guarding)
NOTE: A minimum or 256 MB cache is required to enable RAID 5, 5+0
support
RAID 1+0 (Striping & Mirroring)
RAID 0 (Striping), RAID 1 (Mirroring)
Embedded NC326i PCI
Express Dual Port
Gigabit Server Adapter Network Interface 10Base-T/100Base-TX/1000Base-TX
Compatibility IEEE 802.3 10Base-T
IEEE 802.3ab 1000Base-T
IEEE 802.3u 100Base-TX
Data Transfer Method PCI Express, four lanes (x4)
Controller BCM5715
Network Transfer Rate 10Base-T (Half-Duplex) 10 Mb/s
10Base-T (Full-Duplex) 20 Mb/s
100Base-TX (Half-
Duplex) 100 Mb/s
100Base-TX (Full-
Duplex) 200 Mb/s
1000Base-TX (Half and
Full-Duplex) 2000Mb/s
Connector RJ-45
Cable Support 10Base-T Categories 3, 4 or 5 UTP; up to 328 ft (100 m)
10/100/1000Base-TX Category 5 UTP; up to 328 ft (100 m)
QuickSpecs
HP ProLiant ML350 Generation 6
Technical Specifications
