HP PROLIANT ML350 G6 - Manual (Page 49)

HP 460W CS HE Power Supply Kit
Part Number
503296-B21
Input Voltage Range (Vrms) 100 to 240
Frequency Range (Nominal)
(Hz) 50/60
Nominal Input Voltage (Vrms) 100 120 200 208 220 230 240
Maximum Rated Output
Wattage Rating 460 460 460 460 460 460 460
Nominal Input Current (A rms) 5.5 4.5 2.6 2.5 2.4 2.3 2.2
Maximum Rated Input Wattage
Rating (Watts) 526 520 505 505 503 503 503
Maximum Rated VA (Volt-Amp) 548 542 527 527 524 524 524
Efficiency (%) 87.5 88.5 91 91 91.5 91.5 91.5
Power Factor 0.97
Leakage Current (mA) 0.42 0.50 0.83 0.87 0.92 0.96 1.00
Maximum Inrush Current (A
peak) 30
Maximum Inrush Current
duration (mS) 20
Maximum British Thermal Unit
Rating (BTU-Hr) 1794 1773 1725 1725 1715 1715 1715
HP 750W CS HE Power Supply Kit
Part Number
512327-B21
Input Voltage Range (Vrms) 100 to 240
Frequency Range (Nominal)
(Hz) 50/60
Nominal Input Voltage (Vrms) 100 120 200 208 220 230 240
Maximum Rated Output
Wattage Rating 750 750 750 750 750 750 750
Nominal Input Current (A rms) 8.9 7.4 4.3 4.1 3.9 3.7 3.6
Maximum Rated Input Wattage
Rating (Watts) 857 847 824 825 820 820 820
Maximum Rated VA (Volt-Amp) 894 884 859 859 854 854 854
Efficiency (%) 87.5 88.5 91 91 91.5 91.5 91.5
Power Factor 0.97
Leakage Current (mA) 0.42 0.50 0.83 0.87 0.92 0.96 1.00
Maximum Inrush Current (A
peak) 30
Maximum Inrush Current
duration (mS) 20
Maximum British Thermal Unit
Rating (BTU-Hr) 2925 2892 2812 2812 2797 2797 2797
QuickSpecs
HP ProLiant ML350 Generation 6
Power Specifications
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011 Page 49
