HP 1200W CS HE Power Supply Kit
Part Number
500172-B21
Input Voltage Range (Vrms) 100 to 240
Frequency Range (Nominal)
(Hz) 50/60
Nominal Input Voltage (Vrms) 100 120 200 208 220 230 240
Maximum Rated Output
Wattage Rating 800 900 1200 1200 1200 1200 1200
Nominal Input Current (A rms) 9.7 9.0 7.0 6.8 6.4 6.1 5.9
Maximum Rated Input Wattage
Rating 930 1034 1348 1348 1348 1348 1348
Maximum Rated VA (Volt-Amp) 970 1079 1406 1406 1406 1406 1406
Efficiency (%) 86 87 89 89 89 89 89
Power Factor 0.97
Leakage Current (mA) 0.42 0.50 0.83 0.87 0.92 0.96 1.00
Maximum Inrush Current (A
peak) 30
Maximum Inrush Current
duration (mS) 20
Maximum British Thermal Unit
Rating (BTU-Hr) 3174 3530 4600 4600 4600 4600 4600
NOTE: To review typical system power ratings use the HP Power Advisor which is available online located at url:
www.hp.com/go/proliant-energy-efficient or www.hp.com/go/hppoweradvisor .
NOTE: Option Kits contain optional power supply, an IEC power cable and PDU IEC cables.
QuickSpecs
HP ProLiant ML350 Generation 6
Power Specifications
